T1000型.圆柱孔调心球高温轴承
分类:圆柱孔调心球高温轴承
轴承介绍
T1000型.圆柱孔调心球高温轴承
Type T1000. Cylindrical hole of self-aligning ball bearing
T10000型.圆柱孔调心球高温轴承,具有自动调心性。该型适用于非常温环境下,主机两端轴(轴承)安装无法严格同心时的径向负荷上使用。
有保特器,适用于转速:100S/min以上中、高速;无保特器适用于转速:100S/min以下。双列满球,载荷面增大,使用寿命长。
Type T10000. A cylindrical bore self- aligning ball bearing, with automatic aligning. This type is suitable for high temperature environment, the host end shafts ( bearing ) installation could not be strictly concentric when the radial load on the use of.
A security device, suitable for speed: 100S / min above, no special device is suitable for high speed; speed: 100S / min. Double row full complement ball, loading surface increases, long service life
常年生产.表2 Table 2 annual production
型号 Typws |
|
外形 d x D x B |
重量 公斤/套 |
型号 Typws |
|
外形 d x D x B |
重量 公斤/套 |
|
|
||||||
T1200 |
10×30×9 |
0.035 |
T1300 |
10×35×11 |
0.06 |
||
~ |
~ |
~ |
~ |
~ |
~ |
||
T1222 |
110×200×38 |
5.2 |
T1322 |
110×240×50 |
11.93 |
||
T2204 |
20×47×18 |
0.152 |
T2304 |
20×52×21 |
0.22 |
||
~ |
~ |
~ |
~ |
~ |
~ |
||
T2222 |
110×200×53 |
6.66 |
T2322 |
110×240×80 |
17.6 |
