TUC0000型.外球面高温轴承
分类:外球面高温轴承
轴承介绍
TUC0000型.外球面高温轴承
Type TU0000. Outside the spherical bearing
TUC0000型.外球面高温轴承,内圈有锁紧锣丝,外圈外径是球面型,具有静调心功能,对主机制造和安装精度要求低。适用于非常温环境下,径向负荷的主机上使用。
TUC0000 type. The spherical bearing, the inner ring has a locking screw, outer diameter is spherical, with static adjusting function of host manufacture and installation, low requirement of precision. Applicable to high temperature environment, the radial load on the host use.
常年生产.表7 Table 7 annual production.
型号 Typws |
|
外形 d x Dx BxC |
重量 公斤/套 |
型号 Typws |
|
外形 d x Hx L xJx HO x B(BI) |
重量 公斤/套 |
|
|
||||||
TUC202 |
15×40×27.4×14 |
0.11 |
TUCP202 |
15×33.3×127×95×62×27.4 |
0.7 |
||
~ |
~ |
~ |
~ |
~ |
~ |
||
TUC220 |
100×180×108×41 |
4.5 |
TUCP220 |
100×115×380×308×225×108 |
16 |
||
TUC305 |
25×62×38×21 |
0.35 |
TUCP305 |
25×45×175×132×85×38 |
1.4 |
||
~ |
~ |
~ |
~ |
~ |
~ |
||
TUC328 |
140×300×145×73 |
28.5 |
TUCP328 |
140×200×620×500×390×145 |
89 |
